Tire size
16.9-28 Tractor Tires
16.9-28 is a bias farm tractor rear and industrial / tractor loader tire size with R-1 or R-4 treads, used for heavy utility; loader / backhoe.
New and used options. Tell us the quantity, your machine and where to ship.
16.9-28 tires listed now
-
New
22 sizes Ozka KNK50 R-1 Bias Tractor Tire
From $75.00
-
New
16 sizes Ascenso TDB 120 R-1 Bias Tractor Tire
From $264.00
-
New
18 sizes Petlas TA60 R-1 Bias Tractor Tire
From $235.00
-
New
12 sizes Carlisle Farm Specialist R-1 Bias Tractor Tire
From $540.00
-
New
15 sizes Galaxy Earth-Pro R-1 Bias Tractor Tire
From $401.00
-
New
8 sizes Cultor AS-Agri 13 R-1 Bias Tractor Tire
From $560.00
-
New
15 sizes CEAT Farmax R1 Bias Tractor Tire
From $296.00
-
New
9 sizes Mitas TD-02 R-1 Bias Tractor Tire
From $609.00
Not what you need? We source more 16.9-28 tires than we list. Add the size to your quote list above.
What “16.9-28” means
- 16.9Section width: 16.9 in (429 mm)
- -Bias-ply construction
- 28Rim diameter: fits a 28-inch wheel
Where 16.9-28 is used
| Type | Tread | Construction | Typical use |
|---|---|---|---|
| Farm Tractor Rear | R-1 | Bias | Heavy utility |
| Industrial / Tractor Loader | R-4 | Bias | Loader / backhoe |
Buying 16.9-28 tires
16.9-28 does two jobs. On farms it is a rear tire for utility tractors, usually with R-1 bar lugs. On construction and yard machines it is one of the most common rear backhoe loader sizes, fitted with R-4 industrial tread. The size is the same, about 16.9 inches (429 mm) wide on a 28-inch rim, but the two tires are built for different work, so tell us which one you need.
- R-1 (farm): tall, open lugs that dig in and clean out in soil. The best choice for field work.
- R-4 (industrial): shorter, closer lugs for stability and wear on concrete and gravel. The standard for backhoes. See our backhoe and loader tires.
The radial equivalent is 16.9R28, also sold as 420/85R28. Radials ride better on the road; bias tires are cheaper and have the stiff sidewall many loader operators prefer.
What to check
- Tread type: R-1 or R-4. Mixing them on one axle makes the machine pull to one side.
- Ply rating: backhoe rears carry heavy loads, so 10-ply and up is common. Match what you have.
- Used tires: ask for the tread depth and photos. Industrial tires often wear unevenly on hard ground.
Send us the quantity, the tread you need and the delivery location for a quote.
What do 16.9-28 tires cost on our site?
We list 11 models in 16.9-28. 11 have a listed price, from $453 (Petlas TA60) to $1,221 (CEAT Farmax R1) per tire, with a median of $781. Prices are per tire in US dollars and change with stock and season.
| Model | Tread | Load / ply | Price per tire |
|---|---|---|---|
| Petlas TA60 | R-1 | 8PR 135A6 – 14PR 145A8 | $453 |
| Cultor AS-Agri 13 | R-1 | 12 ply TL/TT | $560 |
| Ascenso TDB 120 | R-1 | 8 ply TL | $603 |
| Carlisle Farm Specialist R-1 | R-1 | 8 ply / 10 ply | $665 |
| Ozka KNK50 | R-1 | 8 / 10 / 14PR | $690 |
| Firestone Super All Traction II 23° | R-1 | 6 ply | $781 |
| Alliance 324 FarmPRO | R-1 | 8 ply / 135A8; 12 ply / 143A8 | $800 |
| Mitas TD-02 | R-1 | 10 ply | $1,000 |
| Galaxy Earth-Pro R-1 | R-1 | 8 ply | $1,129 |
| Goodyear Dyna Torque II | R-1 | E/10 ply | $1,218 |
| CEAT Farmax R1 | R-1 | 8 ply | $1,221 |
How tall is the 16.9-28 tire?
The nominal overall diameter is about 56.7 in (1,441 mm), which gives a rolling circumference near 178 in (4,527 mm). That figure is an estimate that assumes an 85% aspect ratio, the usual rule for old inch sizes. Real tires vary by make and load, so treat it as a guide and use the tire diameter calculator or the lead-lag calculator before you change size on a front-wheel-assist tractor.
Is 16.9-28 a radial or a bias tire?
It is a bias-ply size. The dash in the size marks bias construction, which costs less and has stiffer sidewalls. See the radial vs bias guide.
Brands we source
- Michelin
- Bridgestone
- Goodyear
- Trelleborg
- BKT
- Firestone
- Titan
- Alliance
- Mitas
- Continental
- CEAT
- Yokohama Off-Highway
- Nokian Tyres
- Cultor
- Galaxy
- Carlisle
- Petlas
- Ascenso
- Maxam
- Ozka
Brand availability varies by size. Ask us which brands we can supply in 16.9-28, new or used.
